PikoButton is a high-quality and highly durable assistive button. It is made of lightweight yet sturdy material, designed to withstand constant and even heavy use—just as an everyday assistive tool should. The buttons can be used to control various non-life-supporting or non-life-threatening functions, such as assistant calls, environmental control, and communication devices.
PIKOBUTTON 50
Single activation switch.
- 9 different colors: red, green, blue, yellow, orange, black, white, gold and silver.
- Size: Diameter: 50 mm / 2″
- 3 activation forces:
Light: 75 g / 2,6 oz
Medium: 125 g / 4,4 oz
Stiff: 250 g / 8,8 oz - Max. load: 12VDC 50mA
- Connector: 3,5 mm mono
- CE marked medical device.
PIKOBUTTON 30
Single activation switch.
- 9 different colors: red, green, blue, yellow, orange, black, white, gold and silver.
- Size: Diameter: 27 mm / 1,18″
- 3 activation forces:
Light: 75 g / 2,6 oz
Medium: 125 g / 4,4 oz
Stiff: 250 g / 8,8 oz - Max. load: 12VDC 50mA
- Connector: 3,5 mm mono
- CE marked medical device.
pikobutton water resistant 50
Water Resistant PikoButton 50 can be used outside in the rain, to call a nurse when in shower etc.
Water Resistant PikoButton 50 is available in three colors (black, blue, red) and with activation force of 125 g / 4,4 oz.
- Max. load: 12VDC 50mA
- Connector: 3,5 mm mono
- CE marked medical device.
pikobutton water resistant 30
Water Resistant PikoButton 30 can be used outside in the rain, to call a nurse when in shower etc.
Water Resistant PikoButton 30 is available in three colors (black, blue, red) and with activation force of 125 g / 4,4 oz.
Max. load: 12VDC 50mA
Connector: 3,5 mm mono
CE marked medical device.
PIKODUAL 50
Dual activation switch: can be used to perform two different actions.
9 different colors: red, green, blue, yellow, orange, black, white, gold and silver.
Size: Diameter: 50 mm / 2″
3 activation forces:
Light: 75 g / 2,6 oz
Medium: 125 g / 4,4 oz
Stiff: 250 g / 8,8 oz
Max. load: 12VDC 50mA
Water Resistant models IP class: IP67 (immersible under water for 30 minutes)
CE marked medical device.
pikodual 30
Dual activation switch: can be used to perform two different actions.
9 different colors: red, green, blue, yellow, orange, black, white, gold and silver.
Size: Diameter: 27 mm / 1,18″
3 activation forces:
Light: 75 g / 2,6 oz
Medium: 125 g / 4,4 oz
Stiff: 250 g / 8,8 oz
Max. load: 12VDC 50mA
Water Resistant models IP class: IP67 (immersible under water for 30 minutes)
Connector Pikodual: 3,5 mm stereo
CE marked medical device.
fingerbutton
FingerButton is a small single action switch that is placed around a finger with flexible Velcro tape. It is easy to use and extra sensitive.
FingerButton is extremely suitable for people with little strength.
FingerButton is activated with the press of thumb.
Max. load: 12VDC 50mA
Connector: 3.5 mm stereo
CE MDR 2017/745
fingerdual
FingerDual is equally sensitive but has two functions.
FingerDual is activated with the press of thumb.
Max. load: 12VDC 50mA
Connector: 3,5 mm stereo
CE MDR 2017/745
PIKOBUTTON SW5R
Colors: Red, Blue, Green, White, Yellow.
Size: 17 x 49 mm
Activaton force: 125 g
Weight: 18 g
Connector: DB9F
Standard cable: 170 cm
CE marked medical device.
YCABLE
Splitter cable transforms Pikodual or Fingerdual single connector into two separate single function connectors.
Connectors 3,5 mm female 3 pole -> 2 x 3,5 mm male 2 pole
